Autometer Tachometer, Clubman, 80mm, White, 0-6-15K Rpm, Stack Instruments (SKU: STK-ST200-0615W)

For the serious performance enthusiast, the 80mm sized ST200 Clubman tachometer features the unique, extremely rugged STACK stepper-motor movement, with Digital Quartz accuracy for unparalleled precision. Configurable for most engine types utilizing standard and magneto style ignitions, Stack Clubman tachometers come standard with Peak RPM ‘Tell-Tale’ memory, and a built in shift-light activation circuit. Stack panel and dash mount shift lights available separately.

  • Configurable for all negative earth and magneto ignition systems.
  • Unique Stack Stepper-Motor Needle Movement.
  • Unrivalled Digital Quartz accuracy guaranteed for life.
  • Peak RPM ‘Tell-Tale’ memory.
  • User adjustable shift light option (lamp not included).
  • Exceptional reliability.
  • Fully sealed against water and dust to IP67.
  • Fits standard 80mm cut outs.
  • Supplied with mounting bracket, switch kit, and user manual.
  • Maintenance free White LED backlighting on all ST200 models.

SPECIFICATIONS

Series STACK INSTRUMENTS
Product Type Gauge Tachometer
Dial Color White
Lens Style Flat, Clear
Bezel Color Black
Bezel Style Stack
Size (Metric) 80mm
Size (Standard) 3.175"
Cup/Hole Size (Metric) 81.5mm
Cup/Hole Size (Standard) 3.210"
Outer Bezel Diameter 3.470"
Lighting Type LED
Lighting Color White
Pointer Color White
Movement Electric, Digital Stepper Motor
Gauge Type In-Dash Tachometer
Range 0-15,000 RPM
Includes (Replacement) Wire Harness Yes
Includes (Replacement) Mounting Hardware ST913029
Instruction Manual Part Number 2650-1750
