K Series 3 Piece Carbon Rod End, 1-1/2in. Bore, 1-1/2in.-12 RH Female Thread (PART #QA1-KFR24)

QA1's

KF Series

large bore alloy steel female rod ends are constructed using a three-piece design using hardened bearing steel ball/race. The ball and race are MoS2 (Molybdenum Disulfide) coated to reduce friction and wear. These precision rod ends are designed for heavy-duty/high-load applications.

"¢ BALL: 52100 Bearing Steel, Heat Treated, MoS2 Coated

"¢ RACE: 52100 Bearing Steel, Heat Treated, MoS2 Coated, Sealed

"¢ BODY: Alloy Steel, Protective Coated for Corrosion Resistance

SPECIFICATIONS

Rod End Series K Series
Style/Construction 3 Piece Carbon
Bore 1.5000in.or 1-1/2in.
Thread Direction RH
Thread Size and Pitch 1-1/2in.-12
Male or Female Thread Female
PTFE Lined? No
Configuration Standard
