GM Performance Valve Spring, LS6, Single, Beehive Style, 1.800 in. Installed Height, Each (PART #GMP-12625033)

Looking to replace those worn-out valve springs? Look no further--GM Performance has you covered. These stock diameter LS6 valve springs fit your stock heads without any modifications, and are made of high-quality material for durability and the right performance.

SPECIFICATIONS

Brand Chevrolet Performance
Manufacturer's Part Number 12625033
Part Type Valve Springs
Product Line Chevrolet Performance LS6 Valve Springs
Valve Spring Style Beehive
Number of Springs Per Valve Single
Retainers Included No
Outside Diameter of Outer Spring (in.) 1.290 in.
Coil Bind Height (in.) 1.200 in.
Damper Spring Included No
Spring Rate (lbs./in.) 375 lbs./in.
Locks Included No
Valve Stem Seals Included No
Valve Springs Coated No
Remanufactured No
Quantity Sold individually.
Notes GM production 2004-04 LS6 Corvette Z06 valve spring.
