Cartech Books, How To: Rebuild & Modify GM Turbo 400 Transmission
Part Number:BOK-CT-SA186
Cartech Books, How To: Rebuild & Modify GM Turbo 400 Transmission (PART #BOK-CT-SA186)
Over the last 50 years, literally millions of GM cars and trucks have been built with Turbo 400 automatic transmissions. While these transmissions are respected for their durability and versatility, there always comes a point where the old transmission shows signs of wear. At some point, even the best transmissions need to be rebuilt.
Respected automotive technical author Cliff Ruggles takes readers through the complex rebuild procedure of GMs most popular rear-wheel drive automatic transmission in this great new book. Enthusiasts have embraced the reliable GM Turbo Hydra-Matic 400 three-speed automatics for years, and the popularity of these transmissions is not slowing down. With his proven style, Ruggles walks through the step-by-step rebuild and performance upgrade procedures in a series of full-color photos for each of these models. Time saving tips are part of every buildup.
This is a welcome addition to your automotive library. Amateurs and professionals alike will appreciate the advice and guidance offered on every page. Even if you end up deciding to have a professional take care of your transmission repair and performance needs, this information is crucial to understanding how the power gets from the engine to the road.
TABLE OF CONTENTS |
|
Preface
What is a Workbench® Book?
Chapter 1 |
Tools and Equipment Safety Equipment Sockets and Wrenches Snap Ring Pliers Screwdrivers Measuring Devices Spring Compressors Case Holding Fixtures Work Surface Pans for Small Parts Cleaning Cases Bushing Removers and Installers Heli-Coils and Bolt Extractors Air Tools Punches, Chisels and Files Lip Seal Installation Tools Friction Alignment Tool Oil Pump Band Alignment Studs Slide Hammer Special Tools
Chapter 2: Transmission Fundamentals Torque Converters Transmission Oil Pump Clutch Packs Bands and Servos Accumulators Planetary Gears Sprags and Roller Clutches Valve Body
Chapter 3: Transmission Removal
Chapter 4: TH400 Disassembly Remove External Components Remove Valve Body and Governor Filter Remove Downshift Solenoid and Separator Plate Remove Front Band and Low Band Apply Servos Remove Oil Pump, Manual Shaft and Speedometer Gear Housing Remove Forward Drum Clutch, Direct Drum and Band Remove Clutch Pack, Output Shaft and Low Band Final Disassembly
Chapter 5: TH400 Assembly Install New Case Bushing, Solenoid Connector and Parking Pawl Disassemble Output Shaft and Lower Planetary Assembly Reinstall Planetary Assembly Install Low Band and Output Assembly Rebuild Center Support Reinstall Center Support Rebuild and Install Clutch Pack and Intermediate Band Rebuild Direct Clutch Pack and Install Direct Drum Rebuild Forward Drum Rebuild and Install Oil Pump Assembly Check Clutch Packs and Install Accumulator Piston Install Filter and Valve Body Install Exterior Components
Chapter 6: TH400 Transbrake Installation Procedure
Chapter 7: Transmission Installation
Troubleshooting Guide
Source Guide |
SPECIFICATIONS |
|
| Pages | 144 |
| Size | 8.5 X 11 (inches) |
| Format | Paperback / softback |
| Illustrations | 407 Color Photos |
| Publisher | CarTech |
| ISBN | 9781934709207 |
| Product Code | SA186 |
| ISBN | 9781934709207 |
| Product Code | SA186 |
